Rubber flooring for stable walkways

By using our flexible and non-slip rubber mats, you ensure a secure footing in your stable walkways. We’ve all experienced the problem that our horses are often in a rush to get into or out of their stable. If the horse slips, it could lead to a serious accident.



Our rubber mats will also reduce noise levels, making your stable a more peaceful place.



Eldorado-puzzle mat with horse head profil

The Eldorado interlocking mat can be joined so well that it creates an almost seamless covering. This provides the perfect flooring for your horse.





Measurements:



  • Available in two different sizes
  • Thickness: 16 mm
  • Colour: black
  • Top surface: Horse’s head profile
  • Underside: Groove profile
  • Interlocking joint system
  • Depending on the area there is hardly any wastage thanks to the addition of half Eldorado interlocking mats (0.50 m x 1.00 m)

Mat sizes available:



  • 1.00 m x 1.00 m                                          (Interlocking system on 4 sides)
  • 0.50 m x 1.00 m                                       (interlocking system on 3 sides - 1 long side without interlocking tabs)

Bedding recommendations:



We recommend the use of high-absorbency bedding (wood shavings or similar). The bedding will also help to seal the joints. Any remaining liquid that seeps between the mats will evaporate.



Subsurface:



The subsurface must be level and sealed, concrete or paving. No incline needed.



Information on cutting can be found here.



Low emissions product see Test PDF



SAGUSTU-elastic-composite paving stones

The outstanding non-slip properties of our flexible interlocking paving stones make them highly recommended for use in stable walkways. And they look great too.



Measurements:



  • Size: 20 cm x 16.5 cm (each stone)
  • 35 stones cover 1m²
  • Thickness: 43 mm
  • Colour: reddish-brown, black or green
  • Upper surface: open pore structure, compressed incl. fibres
  • Underside: open pore structure, compressed incl. fibres
  • Half-stones and edges also available

Subsurface:



Can be laid on concrete, concrete paving or a bed of gravel / chippings (firm and level). There should be a slope of around 2-3 % and a drain.





We recommend fixings around the edges (e.g. wooden or aluminium rail) to prevent slipping.



Information on cutting can be found here.



SAGUSTU-elastic-composite paving mat

Due to their size, our interlocking paving mats are quick and easy to install in larger stable walkways, and don’t forget, they're non-slip and look great too.



Measurements:



  • Size: 1.00 m x 1.12 m
  • Thickness: 43 mm, 30 mm and 15 mm
  • Colour: reddish-brown, black or green
  • Top surface: ring matting
  • Underside: drainage grooves (43 mm + 30 mm)
  • Underside: smooth (15 mm)
  • Mats lock together

Subsurface:



Can be laid on concrete, concrete paving or a bed of gravel / chippings (firm and level). There should be a slope of around 2-3 % and a drain.





We recommend fixings around the edges (e.g. wooden or aluminium rail) to prevent the rubber mats from slipping.



Information on cutting can be found here.



SAGUSTU-rubber wedge

The SAGUSTU Rubber Wedge provides an unimpeded transition. The Rubber Wedge helps to avoid tripping.



Measurements:



  • A choice of measurements is available:

      - 0.50 m x 0.13 m x 40 mm



      - 0.50 m x 0.20 m x 43 mm



  • Colour: reddish-brown or black
  • Top surface: ring matting
  • Underside: ring matting



Subsurface:



Can be installed on concrete or concrete paving (solid surface).



Mounting:



May be glued or screwed. When using screws, washers should be used to ensure that the screws do not pull through the rubber.



Information on cutting can be found here.



SAGUSTU-massiv-walkway flooring

Surface hammer groove, underside smooth or fabric textured. Impermeable to water and urine, non-slip, sound-deadening, easy to clean and simple to install as it is supplied rolled.



Measurements:



  • Thickness: 8 mm (other thicknesses available with different delivery times)
  • Supplied rolled
  • No fibres or reinforcement
  • Colour: black
  • Roll width: up to 2.50 m
  • Roll length: up to 30 m
  • Underside: smooth (up to 2.00 m)
  • Underside: fabric pattern (2.50 m)
  • Various roll widths and lengths available from stock.



Subsurface:



Can be installed on concrete or concrete paving (solid surface).



Mounting:



We recommend securing the rolled mats to prevent them from slipping. One option is to screw through the solid rubber mats. When using screws, washers should be used to ensure that the screws do not pull through the rubber. Alternatively, a wood or aluminium edging strip can be used as a frame.



Information on cutting can be found here.



SAGUSTU-walkway flooring patterned fabric on both sides

Impermeable to water and urine, highly non-slip, sound-deadening and simple to install as they are supplied rolled.



Measurements:



  • Thickness: 6 mm or 8 mm
  • Supplied rolled
  • No reinforcement
  • Colour: black
  • Roll width: up to 1.80 m
  • Roll length: up to 21 m
  • Various roll widths and lengths available from stock.



Subsurface:



Can be installed on concrete or concrete paving (solid surface).



Mounting:



We recommend securing the rolled mats to prevent them from slipping. One option is to screw through the solid rubber mats. When using screws, washers should be used to ensure that the screws do not pull through the rubber. Alternatively, a wood or aluminium edging strip can be used as a frame.



Information on cutting can be found here.



SAGUSTU-liquid rubber flooring

Other uses:



  • Zoo floors
  • Stables
  • Animal shelters
  • Dog kennels

We’d like to draw your attention to the fact that SAGUSTU Rubber Screed is made of natural rubber and is solvent-free. This environmentally-friendly composition means that a chalky deposit may form on the surface at certain levels of humidity or residual moisture in the ground beneath it. This can be removed using a standard limescale remover. Slight hoofprints are created in the surface when the puffy upper latex layer gets squashed. This squashing function is important for the stability of the horse; it will not damage the covering. Installation instructions will be supplied when your goods are delivered, once you have placed your order.

 Seamless installation creates a permanently smooth rubber flooring which is impermeable to water. Impervious to PH neutral cleaning agents. A coating thickness of 20 mm is recommended in the stable area and veterinary hospitals. Installation on wood, concrete, interlocking paving, metal and other surfaces possible. The surface can be made smooth and closed cell with the aid of a spiked roller. If installed in an outdoor area, the surface must be covered and rising damp must be avoided. On-site professional installation by our experienced team possible on request.





Content:



  • 3 components (rubber granulate, natural rubber, binding agent)
  • Black colour (other colours - red-brown or dark green - available at additional cost)
  • Weight approx. 50 kg / pack
  • Yield per coating thickness
  • from 15 mm: 3 sqm / pack
  • Yield per coating thickness
  • from 20 mm: 2.25 sqm / pack

Repair packs with the following yields when laid at a thickness of 10 mm are also available:

  • 2 sqm / pack
  • 1 sqm / pack
  • 0.5 sqm / pack ("mini repair kit")

Measurements:



  • 3 components (rubber granulate, natural rubber, binding agent)
  • Colour black (other colours reddish-brown, dark green for an additional charge, please enquire for prices) weight approx. 50kg / pack
  • Yield per coating thickness
  • from 15 mm: 3 sqm / pack
  • Yield per coating thickness
  • from 20 mm: 2.25 sqm / pack
